CCS Combo2 To TPC AC DC in One
CCS Combo2 to TPC AC DC in One is a cutting-edge product designed to meet the evolving demands of the electric vehicle industry. This innovative solution allows for seamless charging of electric vehicles by integrating both CCS Combo2 and TPC AC DC charging protocols in a single device.
CCS Combo2 to TPC AC DC in One is a cutting-edge product designed to meet the evolving demands of the electric vehicle industry. This innovative solution allows for seamless charging of electric vehicles by integrating both CCS Combo2 and TPC AC DC charging protocols in a single device.
With its compact and user-friendly design, this product provides convenience and ease of use for electric vehicle owners, while also delivering superior performance and reliability. The CCS Combo2 to TPC AC DC in One is built with high-quality materials and features advanced safety mechanisms to ensure the protection of both the vehicle and the user during the charging process.
This product is ideal for charging stations, commercial and residential properties, and public areas where electric vehicles are commonly parked. It is compatible with a wide range of electric vehicles and supports fast charging capabilities to reduce charging time and increase convenience for users.
Features
1. Meet IEC 2011 Standard 62196-3 SHEET 3-Im
2. Concise appearance, support rear installation
3. Back Degree of protection IP55
4. Maximum charging power: 127.5KW
5. Maximum AC charging power: 41.5KW
Mechanical Properties
1. Mechanical Life: No-load plug/pull out (10000 times)
2. Influence of external force: can afford to fall 1m and exceed 2 tons vehicle over pressure?
Electrical Performance
1. DC Input: 80A, 125A, 150A, 200A 1000V DC MAX
2. AC input: 16A 32A 63A 240/415V AC MAX
3. Insulation resistance: ＞2000MΩ（DC1000V）
4. Terminal temperature rise: ＜50K
5. Withstand voltage: 3200V
6. Contact Resistance: 0.5mΩ Max
Materials Used
1. Housing material: Thermoplastic flame retardant grade UL94 V-0
2. Pin: copper alloy, silver + thermoplastic on top
Environmental performance
1. Working temperature: -30°C~+50°C
Model selection and standard wiring
The CCS Combo2 to TPC AC DC in One is a game-changing solution that provides a seamless and reliable charging experience for electric vehicle owners, while also meeting the growing demands of the electric vehicle industry.
Purchasing our CCS Combo2 To TPC AC DC in One product comes with a multitude of advantages.
First and foremost, our product is designed with the highest quality and safety standards in mind. It has undergone rigorous testing and certification to ensure that it meets all applicable regulations and standards.
In addition, our CCS Combo2 To TPC AC DC in One product offers exceptional convenience and versatility. It can be used to charge electric vehicles with both AC and DC power, making it an ideal solution for a wide range of applications.
